Features:
- Combination hammer with 2 functions: hammer drilling, drilling, and chiseling
- Metabo VibraTech (MVT): integrated damping system to reduce vibrations in order to protect the user’s health
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for working at customized speeds to suit the application material and speeds that remain almost constant, even under load
- Thumbwheel for Speed Preselection and Impact Rate
- Electronic soft start for precise spot-drilling
- Metabo S-automatic torque limiting clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly.
- Wear indication for carbon brushes
- Lockable switch for trouble-free working in continuous operation
Specifications:
- Max. single blow energy (EPTA) 20 J
- Amps 15 AMPS
- Maximum impact rate 1950 BPM
- Rated input power 1700 W
- Max. capacity in concrete with hammer drills 2 “
- No-load speed 125 – 250 RPM
- Bit retainer SDS-max
- Collar diameter 2 7/8 “
- Weight (without power cable) 26 lbs
- Cable length 20 ft
- Hammer drilling concrete 12.4 m/s²
- Uncertainty of measurement K 2 m/s²
- Chiseling 11 m/s²
- Uncertainty of measurement K 2 m/s²
- Sound pressure level 100 dB(A)
- Sound power level (LwA) 111 dB(A)
- Uncertainty of measurement K 3 dB(A)
Includes:
